Advanced Vector Signal Analyzer Software
89600 VSA 2026 Update 2 has been and includes feature updates for Digital Demod, Custom OFDM (6GR presets), 5G NR, WLAN, DVB-RCS2, and more, as well as new hardware connectivity support.
Check out what’s included.
Basic VSA and Hardware Connectivity (8960120xC)
- Change node-locked and transportable licenses from CCL-license (Host ID) to KAL-license (MAC address)
- Analysis support for VXT M9415B with BBIQ, XR8 scope XR804KA, PNA-X Pro NA520xA, FieldFox D models N99xxD
- Upgrade UXR from 2 channels to 4 channels
- Source control support for M8190A/95A AWG and AP5041A/42A VSG
Digital Demod (89601AYAC)
- Custom IQ: add presets for cross-QAM (32 to 32768QAM) and square-QAM (4096 and 16384QAM)
- Custom IQ: save constellation to Signal Studio format
- FlexFrame: extend QAM constellation presets (32 through 32768 QAM)
FlexFrame Waveform Generation (89602AYAC)
- IQ impairment support with user-defined or measured distortion
Custom OFDM (89601BHFC)
- Extend the max number of channels from 8 to 64
- 6GR (6G Radio FR1/FR3) presets
5G NR/5G-Advanced (89601BHNC)
- SINR report visualization
- PDSCH and PUSCH data only rate match
Pulse Analysis (89601BHQC)
- Advanced radar adds Range-Doppler Analysis
WLAN Modulation Analysis (89601BHXC)
- 802.11bn distributed RU (dRU-60) support
- Integrate SEM and EVM measurements (for all legacy WLAN except 802.11bn)
DVB SatComm (89601DVBC)
- Add DVB-RCS2 return link modulation analysis
- Support DVB-S2X dummy frame
DVB SatComm Waveform Generation (89602DVBC)
- Generate DVB-S2/S2X/RCS2 ideal waveforms and apply pre-distortion and/or AWGN
- Recall as a recording, download to a signal generator, and save to file(s)
Stimulus Response (89601CSDC)
- Renaming from channel sounding to stimulus response
- Include both channel sounding measurement (89601CSDC) and advanced component test features (89601CTMC)
